RAVE-S®
S-PERIENCE
Discover RAVE-S®, our compact 160° Sideshooter Cube with the reach of a larger light. Approved for road use, combined with exceptional light output, the RAVE-S® is the first choice for applications where a small size with maximum light output is a priority.
In addition to its aesthetic design, the series is functionally outstanding, with the aerodynamic shape minimizing airflows and resistance even at high speeds.
Experience this unique product today and shop directly from the manufacturer online. Available now, with fast shipping. Welcome to LTPRTZ!
COMPACT. POWER
Small. Wide beam with great range.
Position light.
High beam.
E-Mark.
All of this is the RAVE-S®
FEATURES
✔ Water and dustproof, shock-resistant
✔ Made from the highest quality materials
✔ Compact size fits many applications
✔ Usable in ambient temperatures from -40°C to +80°C
✔ Certification for electromagnetic compatibility
✔ Reference number: 12.5
✔ Range: 250m (1 Lux)
TECHNICAL DATA
-
Operating Voltage: 9-33V DC
-
Power Consumption (12/24V) :
- Parking Light 1.9W/2.3W | High Beam 29W/28W
-
Housing: Aluminum ADC12
-
Lens and Reflector: Polycarbonate
-
Mounting: Stainless Steel
-
Connection: Deutsch 3-pin
-
ECE Homologation:
R10 | R148 | R149
-
LEDs: 16x High Power
-
Light Color: White
-
Luminous Intensity: 62,000 cd
-
Protection Class: IP69K
-
Dimensions:
89 x 78 x 57 mm
RANGE
The 3.5 Inch RAVE-S from LTPRTZ not only impresses with its unique design but also with first-class performance in terms of illumination, range, and functionality. Over 250m at 1 Lux allows you to experience daylight-bright adventures even at night. In addition to the ECE approval as a high beam, the white background light is also approved as a position light and is road-legal according to STVO. Please check with your local dealer or TÜV/DEKRA branch for country-specific regulations on mounting positions and usage.
CONNECTION
Connection for 2x Additional Headlights
RAVE-S | White
- Relay wiring kit with 3-pin DT connector
- Includes toggle switch or
optional for connecting the Can Bus high beam control
- Connectors for switch connection included
- 40A high-performance relay and fuse holder
with 30A plug-in fuse
- Cable length: 3 m
- 2 pieces Deutsch 4-pin connectors
- Battery + and - ring terminals for M8
RAVE-X®
The 7 Inch RAVE-X is the larger and even more powerful brother of the 3.5 Inch RAVE-S.
Now NEW with background light in AMBER-ORANGE!
